FEATURES

● High quality Taut Band movement. ● Battery operated. ● Solid state circuitry. ● Battery check feature. ● Automatic circuit discharge. ● Three insulation test voltages(DC) : 250V, 500V, 1000V ● Continuity test : 50 Ω ● AC voltage measurement : 500V ● Color-coded scale. ● Fuse protected.

SPECIFICATIONS

Insulation  Resistance      Test voltage (DC V)  250V     /    500V    /    1000V  Output voltage on  open circuit  Rated test voltage +10%  Measuring ranges  0-100MΩ / 0-200MΩ /  0-400MΩ  Accuracy ±5% of indicated value Short circuit current 2mA DC Power consumption 190mA Continuity      Measuring ranges 0 -50Ω & ∞  Accuracy ± 5% of scale length Open circuit voltage 4V DC Approx. Short circuit current 145mA DC Approx. Power consumption 200mA AC Voltage      Range  0-500V AC  Accuracy  ± 2.5% of full scale  Line frequency range  40 -1k Hz General      Dimensions (with housing front cover) 175(L) × 85(W) × 75(D)mm  Weight  (battery included)  Approx. 600g  Power source 1.5V (AA) × 8  Safety standard  EN 61010-1 CAT III 500V  EN 61326-1
