Milli-Ohm meter/Micro-Ohm meters

  • Filter

* Professional bench type milliohm meter.* 20 m /200 m /2 /20 /200 /2 K /20 K ohm.* 20,000 counts, Jumbo LCD with back light.* Hi / Lo warning, 4 wires terminals, Kelvin clips is included, 0.001 milliohm resolution.* Judgement output : Low/Good/High port, used for the automatic machine to select the components (good or no good).* Power : AC 110V or AC 220 V/AC230 V.

Maximum test current of 10A (60 mΩ) Best resolution of 1μΩ, (accuracy 0.05%) Measures resistive and inductive materials Selection of 6 Current ranges - Manual or Auto Programmable Hi-Lo alarm with memory of 20 readings Auto-display of: • Hi (readings higher than Hi-Limit)• Lo (readings lower than Lo-Limit)• Pass (readings between Hi-Limit and Lo-Limit) Memory of 3000 sets of data Measure cable length in metric and imperial units Cummunicate with PC via USB or RS232C Rechargeable batteries and AC Adapto

3-1/2 digit LCD display with maximum reading of 2000. Low battery indication. Zero adjustment: External zero adjustment control. Very low impedance measurement, four-wire type, one pair insulated clip. Wide measurement range 1 milliohm to 20k Ohm in six switchable steps. Fuse protection: 2 Amp/250Volt (5mm x 20mm), fast minimum interrupt ratings 1500A. Function keys: D-H switch lockup readings for LCD display. Dimensions: 160mm (L) x 100mm (W) x 52mm (D) Weight: 700g approx.

  FEATURES* 4 terminal devices for accurate measurement of very low resistance.* Ideal for measuring the resistance of components precisely.* Ideal for testing protective conductors, lightning conductors and welded points.* Maximum test current is 10A ( 60000uΩ range only ).* Have two working mode , Resistive and Inductive mode, Normal is resistive mode.* Good / Fail set-function for input quality control.* Built-in in buzzer sound (GOOD STATUS) to assist the Q.C. judgment.* Especial "CALCULATE" function to measure cable / wire length.
